4
ELF System
Copper / Fiber :: ELF Family
ELF Module Conguration ELF Model
Number
Page Illustration
12-Termination
Splice/
Patch
REAR —
• Subunit Entrance
FRONT —
• Fiber Adapters
ELF-SP12-SCPT
ELF-SP12-FCPT
34
12-Termination
SC-APC
Patch Module
REAR –
• Fiber Jumpers
from NEs
FRONT –
• Fiber Adapters
ELF-PC12-SA00 33
12-Termination
SC/APC
Patch and
Splice Module
REAR –
• Subunit Entrance
FRONT –
• Fiber Adapters
ELF-SP12-SAPT 33
General Purpose Signal Management
NOTE: All DS1 and DS3 Total Front Access and 12x4 Alarm Pin Block ELF Modules t Telect’s ELF
Wall Bracket (ELF-000-0600).
