Feature
SAF
Code
Description
XStream IP
™
DVB-S2
• IP-over-DVB encapsulation. Supports the
transmission of IP packets with/without Ethernet
frames over DVB-S2/DVB-S2X using Multiprotocol
Encapsulation (MPE) (EN 301 192), Unidirectional
Lightweight Encapsulation (ULE) (RFC 4326) and
Paradise XStream Encapsulation (PXE).
• ACM. Enables DVB-S2/DVB-S2X Adaptive Coding
and Modulation (ACM).
• VCM. Allows either two ASI streams, or one ASI
stream and one IP stream, to be multiplexed onto a
single carrier.
DVB
-
S2
X CCM
Tx
S2XT Enables DVB-S2X Tx operation for all supported
modulations. Includes XStream IP™ DVB-S2.
DVB
-
S2
X
CCM
Rx
S2XR Enables DVB-S2X Rx operation for all supported
modulations. Includes XStream IP™ DVB-S2.
DVB
-
S2 Tx
DVB2T Enables DVB-S2 Tx operation for all supported
modulations. Includes SmartLink™ and XStream IP™
DVB-S2.
DVB
-
S2 Rx
DVB2R Enables DVB-S2 Rx operation for all supported
modulations. Includes SmartLink™ and XStream IP™
DVB-S2.
D
VB
-
S2X Low
-
latency
Mode
S2XLL Enables the following proprietary extensions to DVB-
S2X:
• Very Short Frame: Frame size of 5,400 bits,
reducing latency to 33% of standard DVB-S2 Short
frame; supports QPSK/8PSK/16APSK/32APSK
2/5, 7/15, 8/15, 3/5, 2/3, 11/15, 4/5, 13/15, 14/15
• Ultra Short Frame: Frame size of 3,240 bits,
reducing latency to 20% of standard DVB-S2 Short
frame; supports QPSK/8PSK/16APSK/32APSK
1/3, 4/9, 5/9, 2/3, 7/9, 8/9
ClearLinQ™
Adaptive
Tx Predistorter
CLNQ Corrects for linear and non-linear distortion in the RF
chain. Applicable to all FECs and modulations
including DVB-S2X, FastLink™ and TPC.
FastLink
™
LDPC
FL
Enables
FastLink
™
low-latency LDPC to the
prevailing data rate of the modem (subject to maximum
data rate of 100Mbps). Includes all relevant
modulations and FEC rates.
Paired Carrier
™
56kbps to 256kbps
PCMZ
Enables
Paired Carrier
™
data rates in the given range
(inclusive). Incorporates ViaSat’s patented PCMA
technology. For all supported data rates, Paired
Carrier™ is subject to a minimum occupied bandwidth
of 30kHz and a maximum of 54MHz.
Paired Carrier
™
256kbps to 512kbps
PCMA
Enables
Paired Carrier
™
data rates in the given
range.
Paired Carrier
™
512kbps to 1.024Mbps
PCMB
Enables
Paired Carrier
™
data rates in the given
range.
Paired Carrier
™
1.024Mbps to 2.5Mbps
PCMC
Enables
Paired Carrier
™
data rates in the given
range.
Table 5-2 Software Activated Features (continues over page)
