Feature
SAF
Code
Description
Paired Carrier
™
2.5Mbps to 5Mbps
PCMD Enables Paired Carrier™ data rates in the given range.
Paired Carrier
™
5Mbps to 10Mbps
PCME Enables Paired Carrier™ data rates in the given range.
Paired Carrier
™
10Mbps to 15Mbps
PCMF Enables Paired Carrier™ data rates in the given range.
Paired Carrier
™
15Mbps to 20Mbps
PCMG Enables Paired Carrier™ data rates in the given range.
Paired Carrier
™
20Mbps to 25Mbps
PCMH Enables Paired Carrier™ data rates in the given range.
Paired Carrier
™
25Mbps to 30Mbps
PCMI Enables Paired Carrier™ data rates in the given range.
Paired Carrier
™
30Mbps to 40Mbps
PCMJ Enables Paired Carrier™ data rates in the given range.
Paired Carrier
™
40Mbps to 50Mbps
PCMK Enables Paired Carrier™ data rates in the given range.
Paired Carrier
™
50Mbps to 60Mbps
PCML Enables Paired Carrier™ data rates in the given range.
Paired Carrier
™
60Mbps to 80Mbps
PCMM Enables Paired Carrier™ data rates in the given range.
Paired Carrier
™
80Mbps to 100Mbps
PCMN Enables Paired Carrier™ data rates in the given range.
Paired Carrier
™
100Mbps to 160Mbps
PCMO Enables Paired Carrier™ data rates in the given range.
Optimised spectral roll
-
off
ROFF Enables 5%, 10% and 15% spectral roll-off options.
Wideband
WRF Extends L-band operation upper frequency limit from
2050MHz to 2150MHz.
DVB
-
CID
CID
DVB Carrier ID
.
Tx carrier identification per ETSI 103
129.
Packet
Synchronisation
PTP Supports IEEE 1588 Precision Time Protocol Version
2.
IBS
IBS Enables IBS service (to IESS 309) with low-rate
Intelsat ESC (to IESS 403) and high-rate IBS ESC.
Legacy FECs
IRS
SEQ
TCM
TPL
TPH
Enables
Sequential
FEC (limited to 2.048Mbps);
TCM
8PSK 2/3 to IESS 310; Viterbi BPSK/QPSK/OQPSK
FEC rates 1/2, 3/4 & 7/8; Intelsat Reed-Solomon outer
codec
LinkGuard
™
LG
LinkGuard
™
signal-under-carrier interference
detection.
Table 5-2 Software Activated Features
