ADR-7000 / SAVER-7000 / GUARD-7
© 2017 – Telefire Fire & Gas Detectors Ltd Revision 0.98 October 2017
– Page 23 of 87 –
Figure 5 Mounting
Figure 6 Flush Mounting
The wiring opening on the top right of the cabinet should be covered with a metal sheet.
If no wires enter the cabinet through this opening close it with the plain cover, otherwise
use the cover with two round holes and a plastic sealing grommet.
