TTE Combo Communication Module – Installation and Programming Manual
14
Description of the fields
• “Ademco CID Panel Phone” – Enter a phone number for connection between the control
panel and TTE Combo. The phone number can be up to 16 digits long, as spaces, letters
and special symbols are not allowed.
Note: You must set the same phone number to the control panel, in the digital communicator
programming menus. The “Contact ID (CID)” communication protocol must be set for
reporting in the digital communicator menus also.
Useful Tip: In case of connection to Eclipse control panel, enter into engineering programming
menus “8. COMMUNICATION – 1. DIGITAL COMM – 5. PHONES – 1.PHONE – 1.PHONE
NUMBER”
and set the same phone number set in the “Ademco CID Panel Phone” field. Save
and enter in the next submenu “2.PROTOCOL” to set “CID” type for the communication
• “Panel Line Test Period” – Enter a time interval in minutes (from 2 to 10080) for periodic
test of the connection between the control panel and TTE Combo module. The purpose
of the test is to check the physical connection presence between terminals “A” and “B”
on the digital communicator of the control panel and “ALARM PANEL” terminals of TTE
Combo – see item 2.1 Connection to Burglary Alarm Control Panel
.
In case of trouble with the connection (broken line, disconnection between panel and
module, absence of 220k resistor), a trouble message “Service Required” (“YX” SIA code)
will be sent to the monitoring station. When the connection is restored the monitoring
station will receive a message “Service Completed” (“YZ” SIA code).
When TTE combo is used as standalone device or the testing of the connection with the
control panel is not necessary, the periodic test can be disabled with setting “0” in the
field.
Example: For periodic test at every hour, enter 60; for periodic test at 24 hours – enter
1440, etc.; to disable the periodic test – enter 0.
Useful Information: The used SIA codes and their description are presented in item
7. APPENDIX – SIA CODES
.
• “Account number” - This is the number of the protected site (up to 6 digits), where the
module TTE Combo is installed. In AJAX WEB, this is the number of the registered TTE
Combo module.
• “Password” – User access code for reading/ writing parameters to the module via
ProsTE. The default set code is 1234. To change it you must enter a new 4-digit code into
the field. The code is used also when connecting to AJAX WEB and MobileTTE
application.
• “System ID” –This is a unique name for identification (up to 15 symbols – digits, letters
and special characters), between module and user in the monitoring software.
• “Reporting channels” – Use the drop-down menu to set the type and the way of
reporting of used channels (also called media) for transmitting of events to Receiver
Monitoring station/Server (AJAX SP Pro or SIA-DC09). The user can choose among several
option according the application and needs.
o “LAN is main; GPRS is backup” – The both communication media are used for
reporting. The Alternative reporting
is applied for transmitting of events. LAN
media is the Main media for reporting and GPRS is the Backup one.
o “GPRS is main; LAN is backup” – The both communication media are used for
reporting. The Alternative reporting
is applied for transmitting of events. GPRS
media is the Main media for reporting and LAN is the Backup one.
o “Use only GPRS media” – Only the GPRS channel is used for reporting of events.
