TTE Combo Communication Module – Installation and Programming Manual
5
1.1.1 Functional Features
• Compatible with control panels capable of sending Contact ID (CID)
• Control panel communication supervision
• AES 128 encryption
• Supports 2G networks
• Communication channels – PSTN, LAN and/or GPRS
• Main and Back-up reporting channels
• Connecting to AJAX SP PRO through IP or DNS address
• Supports operation with SIA-DC09 IP protocol messages
• LAN settings – Manual or Automatic (DHCP)
• 1 input (TAMPER/NC to GND)
• 2 outputs OC type
• Internal buffer for 256 events
• Micro USB input for direct PC connection
• Jumper for restoring of the default factory settings
• Reversed polarity protection
1.1.2 Technical Specifications
• Main power supply: ...................................................... 9-30VDC (no tolerance)
• Current consumption:
o Normal operation mode (standby): ........... 100mA
o Maximal consumption: ............................... 200mA
• Time for filtration of signals incoming at I/O: ...............0.3 seconds
• GPRS working frequencies: .......................................... 850/900/1800/1900 MHz
• Antenna connector (internal mounted): ...................... SMA 50Ohm
• Operating temperature: ............................................... -20°C ÷ +60°C
• Dimensions (PCB): ......................................................... 73x108mm
The purpose of this manual is to give directions for programming the TTE Combo module and its
operation with AJAX SP Pro server. You can refer to the installation manual of the module
(applied into the packing box) for details about its elements and PCB hardware.
Find out more materials also at www.teletek-electronics.com.
