ME310G1 Hardware Design Guide
1VV0301588 Rev. 16 Page 22 of 95 2021-10-27
Not Subject to NDA
Pin
Signal
I/O
Function
Type
Comment
N16
ON_OFF*/WAKE*
I
Input Command for Power
ON/OFF and to wake from deep
sleep mode
CMOS 1.8V
Active Low
R1
PWRMON
O
Power ON Monitor
CMOS 1.8V
T2
FORCED_USB_BOOT
I
Optional pin, connect to test
point
CMOS 1.8V
Active high,
Internal PD
(100K)
Audio Section
C1
DVI_WA0
I/O
Digital Audio Interface (WA0)
CMOS 1.8V
D2
DVI_RX
O
Digital Audio Interface (RX)
CMOS 1.8V
E1
DVI_TX
I
Digital Audio Interface (TX)
CMOS 1.8V
F2
DVI_CLK
I/O
Digital Audio Interface (CLK)
CMOS 1.8V
Power Supply
W1
VBATT_PA
-
Main power supply (Radio PA)
Power
AA3
VBATT
-
Main power supply (Baseband)
Power
N4
CTANK
-
Internal supply domain pin for
external tank capacitor
1.8V
Antenna Tuner Section (Only on HW1.0)
G1
ATC1/MIPI_CLK
O
Antenna Tuner Ctrl
Only on HW1.0
J1
ATC2/MIPI_DATA
O
Antenna Tuner Ctrl
Only on HW1.0
H2
ATV
O
Antenna Tuner Voltage
Only on HW1.0
GND
A3
GND
-
RF Ground
Power
A7
GND
-
RF Ground
Power
A9
GND
-
RF Ground
Power
A13
GND
-
RF Ground
Power
A17
GND
-
RF Ground
Power
B4
GND
-
RF Ground
Power
B6
GND
-
RF Ground
Power
B10
GND
-
RF Ground
Power
B12
GND
-
RF Ground
Power
B14
GND
-
RF Ground
Power
B16
GND
-
RF Ground
Power
C19
GND
-
RF Ground
Power
