Telit Wireless Solutions ME310G1 - ME310 G1-W2 Connected Mode

ME310G1 Hardware Design Guide
1VV0301588 Rev. 16 Page 29 of 95 2021-10-27
Not Subject to NDA
Measure
(Typical)
Mode
Description
Connected mode
Average
(mA)
Peak
(mA)
NBIoT
600
1000
3.75KHz subcarrier spacing, 1 SC, RU 32ms, TBS=0, BPSK,
23dBm, Band 85, 28, 12
500
850
3.75KHz subcarrier spacing, 1 SC, RU 32ms, TBS=0, BPSK,
23dBm, Band 13, 26, 5, 18, 19, 20, 8
430
750
3.75KHz subcarrier spacing, 1 SC, RU 32ms, TBS=0, BPSK,
23dBm, Band 3, 2, 25, 4, 1, 66
68
300
15KHz subcarrier spacing, 12 SC, RU 1ms, TBS=5, QPSK,
21dBm, Band 71
88
950
15KHz subcarrier spacing, 12 SC, RU 1ms, TBS=5, QPSK,
23dBm, Band 85, 28, 12
78
800
15KHz subcarrier spacing, 12 SC, RU 1ms, TBS=5, QPSK,
23dBm, Band 13, 26, 5, 18, 19, 20, 8
77
730
15KHz subcarrier spacing, 12 SC, RU 1ms, TBS=5, QPSK,
23dBm, Band 3, 2, 25, 4, 1, 66
GPRS
300
2000
1TX + 1RX, CS1, GMSK, Band 850, 900
170
1000
1TX + 1RX, CS1, GMSK, Band 1800, 1900
Table 19: ME310G1-WW and ME310G1-WWV Connected Mode
4.2.4 ME310G1-W2 Connected Mode
Mode
Measure
(Typical)
Mode
Description
Connected mode
Average
(mA)
Peak
(mA)
CATM
180
400
1 RB, RMC, TBS=5, QPSK,
21dBm, B1, B3, B8, B20, B28
300
680
1 RB, RMC, TBS=5, QPSK
26dBm, B31, B72
NBIoT
245
340
3.75KHz subcarrier spacing, 1 SC, RU 32ms, TBS=0, BPSK,
21dBm, B1, B3, B8, B20, B28
430
570
3.75KHz subcarrier spacing, 1 SC, RU 32ms, TBS=0, BPSK,
23dBm, B31, B72
65
290
15KHz subcarrier spacing, 12 SC, RU 1ms, TBS=5, QPSK,
21dBm, B1, B3, B8, B20, B28
70
430
15KHz subcarrier spacing, 12 SC, RU 1ms, TBS=5, QPSK,
23dBm, B31, B72
Table 20: ME310G1-W2 Connected Mode
