Tellabs 6325 - Page 65

MA365 • Rev. A2 65
Tellabs
®
6325 Edge Node 3 Reference Information
12 Yellow 23 RX12 Grey 73 RX12\ White
Yellow 24 TX12 Blue 74 TX12\ Red
13 Brown 25 RX13 Blue 75 RX13\ White
Brown 26TX13 Orange76TX13\White
14 Brown 27 RX14 Green 77 RX14\ White
Brown 28 TX14 Brown 78 TX14\ White
15 Brown 29 RX15 Grey 79 RX15\ White
Brown 30TX15 Blue 80TX15\Red
16 Black 31 RX16 Blue 81 RX16\ White
Black 32 TX16 Orange 82 TX16\ White
17 Black 33 RX17 Green 83 RX17\ White
Black 34 TX17 Brown 84 TX17\ White
18 Black 35 RX18 Grey 85 RX18\ White
Black 36 TX18 Blue 86 TX18\ Red
19 Grey 37 RX19 Blue 87 RX19\ White
Grey 38 TX19 Orange 88 TX19\ White
20 Grey 39 RX20 Green 89 RX20\ White
Grey 40 TX20 Brown 90 TX20\ White
21 Grey 41 RX21 Grey 91 RX21\ White
Grey 42 TX21 Blue 92 TX21\ Red
--43-
50
- - 93-
100
--
Channel Binder Pin signal
Solid
Color
Pin signal
Solid
Color
