66 MA365 • Rev. A2
Tellabs
®
6325 Edge Node 3 Reference Information
Color coding of open
ended cables
The color coding of the open ended cables are listed in the following table.
Note: The coding of the cable WK-503Y-zz.z-01 is listed in ‘Pin designations
on PIM1 connector and color coding of the E1 cable’ on page 64.
Pin Signal Color code
WK-504Y-zz.z-01 (RJ-45 to open ended)
1TRIBoOrange/White
2TRIBo\Orange
3 Green/White
4 TRIBi Blue
5 TRIBi\ Blue/White
6 Green
7Red/White
8Red
WK-502X-zz.z-01 (9 pole D-dub to open ended)
1GNDWhite
2SYNCiBrown
3 AUX0 Green
4 SYNCo Yellow
5AUX1Grey
6SYNCi\Pink
7AUX2Blue
8SYNCo\Red
9AUX3Black
WK-500Z-02.6-01 (3 pole Molex mini-fit to open ended)
1 0 V (UB-RTN) Brown
2GNDYellow/Green
3 -40.5 to -72 VDC (UB) Blue
