TELSTRA ELITE® GATEWAY USER GUIDE
25
Option Description
Model Name
Themodelnameofthedevice.
Board ID
Thehardwareversionofthedevice
Bootloader version
Thebootloaderversionofthedevice.
Gateway Firmware version
Thefirmwareversionofthedevice.
Wireless driver version
Thewirelessdriverversionofthewirelessmodule.
MAC Address
TheMACaddressofthedevice’sLANinterface.
Serial Number
TheSerialNumberofthedevice.
Network
Thenameoforotherreferencetothemobilenetworkoperator.
Link
ShowstheconnectionstatusofthecurrentNextG™connection.
Mode
TheradioaccesstechniquecurrentlyusedtoenableInternetaccess.
ItcanbeHSUPA,HSDPA,UMTS,orDisconnected.
Selected Signal input
The3Gsignalinputcurrentlyselectedbythegateway.Itcanbe
eitherInternalorExternalantenna(s)
Signal strength
Themobilenetwork(UMTS)signalqualityavailableatthedevice
location.Thissignalqualityaffectstheperformanceoftheunit.If
twoormorebarsareblue,theconnectionisusuallyacceptable.
SIM info
ShowstheSIMcardstatusonthedevice.
LAN IP Address
ShowstheIPaddressforLANinterface.
WAN IP Address
ShowstheIPaddressforWANinterface.
Primary DNS Server
ShowstheIPaddressoftheprimaryDNSserver.
Secondary DNS server
ShowstheIPaddressofthesecondaryDNSserver.
Date/Time
Thetimeaccordingtothedevice’sinternalclock
