23. AIR PRESSURE GAUGE - 105 - 125 psi
optimum operating pressure.
33. JACK SWITCH (RIGHT REAR) - Used in
conjuction with switch (13), to extend and
retract outrigger jack and beam.
24. PARK BRAKE INDICATOR 34. GEAR SELECTOR
25. LOW WATER INDICATOR 35. PARKING BRAKE SWITCH
26. ENGINE STOP INDICATOR 36. AXLE DISENGAGE / RANGE SHIFT
27. ENGINE MAINTENANCE INDICATOR
28. ENGINE STOP / FAULT INDICATOR
53REVISED:
