Side Stow Jib
DESCRIPTION
Two optional jib extensions are available to provide additional boom reach. One is a 32ft
(9.75 m) side stow swing-on one-piece lattice type jib that is offsettable at 0°, 15°, or 30°.
The second jib option is a 33-57 ft. (10.05 - 17.37 m) side stow swing-on lattice type jib.
The jib is extendible to 57 ft. (17.37 m) by means of a 25ft. (7.62 m) manual pullout tip section.
Each optional jib extension is pinned directly to the ends of the sheave pins. When not in
use, the jib can be unpinned from the boom head and stored on mounting brackets on the
right side of the boom base section.
The 32ft (9.75 m) jib weighs 1,280 pounds (581 kg). The 33-57 ft. (10.05-17.37 m) jib weighs
2,070 pounds (939 kg).
Before erecting or stowing the jib, ensure that no personnel or obstacles are in
the swing path of the jib.
RT500
Assembly
36 REVISED:
