7. The BAR GRAPH indicates the ACTUAL
LOAD as a PERCENTAGE OF RATED
CAPACITY.
10. The RADIUS display shows radius of the
load. Radius is the horizontal distance from
the centerline of rotation to the centerline of
the lifting point.
8. The ACTUAL LOAD display shows total
load, including load, slings, etc. suspended
below the lifting point.
11. The LENGTH display shows the length of
the main boom from the boom foot pin to
the sheave pin of the main boom head
machinery.
9. The RATED CAPACITY display shows the
RATED CAPACITY of the crane in the
current configuration.
12. The ANGLE display indicates, in
degrees, the angle of the main boom relative
to horizontal
73REVISED:
