Model TA50RT
Rev. 1 04/99
MAINTENANCE SCHEDULES
5
5 - 6
5.2.2. WEEKLY (continued)
(q) Check the nylon zoom pads for wear as follows:-
(i) Fully zoom in and check the gap at the top of the zoom boom telescope, between the inner and
the outer, at the rear of the zoom boom.
(ii) Fully zoom out and check the same gap at the top of the telescope, at the front of the zoom
outer.
(iii) Renew the pads if the gap between the pad and the zoom outer is 5mm or more.
