TA9 & TA10 Dumper 0803-4 July 2011 10-8
Electric Circuit
Item Description Cable Colour Codes
1 Switch - Hazard lights
B Black
2 Switch - Direction Indicator (A = Left B = OFF C = Right)
G Green
3 Rear indicator lights
K Pink
4 Front indicator lights
LG Light Green
5 Front head lights
N Brown
6 Brake lights
O Orange
7 Number plate lights
P Purple
8 Rear marker lights
R Red
9 Front marker lights
S Slate
10 Switch - Vehicle lights (A = OFF B = Marker Lights C = Head Lights)
U Blue
11 Switch - Brake pressure (brake lights)
T Turquoise
12 Flasher unit
W White
13 Warning Light - Direction indicator
Y Yellow
