ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY.
1 22019 22019 Snap Ring, Spindle 2
2 53009 53009 Axle, Weldment w/Bumber 1
3 22021 1B8.48C8 Bolt,
1
/2" - 13 x 3" NC Gr 8 2
4 28500 IN8CL Nut, 1/2" x 13NC Stover B 2
5 53612 53612 Pin, Front Axle Picot 5
1
/2" Long 1
6 12001 12001 Bushing, 1
3
/4" OD x 1
1
/2" ID x 1" L (Not Shown) 1
7 62022 62022 Motor, Front Drive Torque (Not Shown) 2
8 53083 53083 Tie Rod 1
9 22174 22174 Fitting - 1/4" Straight Male to 1/4" Female Swivel 90° 2
10 81002 81002 Cylinder, Steering 1
11 16066 16066 Bumper 1
12
53002 53002 Spindle, w/Drive Motor Housing - Right 1
53003 53003 Spindle, w/Drive Motor Housing - Left 1
13 53043 3-04.3 Tie Rod Ends 2
Four Wheel Drive Front Axle (Bumper Attached) Serial Number 6980222 & After
1
81013 11
2 3 5
6
7
4
12
2.8
9
