2.25
Top View of Parking Brake Assembly (Prior to SN 6980507)
1 2
5 4 3
NOT SHOWN
ATTACHES TO BRAKE BAND
ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY.
1 55620 5-62M Brake Band 1
2 55606 5-60.6 Brake Cable 1
3 55613 5-61.3DA Brake Off Set Link Not Shown - Attaches to Brake Band 1
4 64003 4-00.3 Drive Motor Torque 1
5 51800 1-80 Drive Motor Flange 1
Copyright © 1999 Terramite Corporation
