Terramite T6 - View from Right Side Top of Swing Assembly

Copyright © 1999 Terramite Corporation
2.46
4
View from Right Side Top of Swing Assembly
ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY.
1 21428 S4MPG Fitting, Grease,
1
/4"-28 Straight 32
2 21206 1-102.01.150 Rod, Boom & Crowd 2
3 82103 82103 Boom/Crowd Cylinder 2
4 20082 IN6CF Nut,
3
/8" NC Flange 24
5 10406 1-04.T6 Pin, 1
1
/2" x 8
1
/4"1
6 17208 17208 Pin, 1
1
/4" x 7
3
/4"1
INSET - SWING CYLINDER SUB-ASSEMBLY
1 82070 82070 Cylinder Assembly, Swing W/Tee Fitting 2
2 20025 20025 Fitting - 90° Tee 2
3 80045 8-4.15 Hose,
1
/4" Swing Crossover, 15" 2
4 20174 0107.4-4 Fitting, Straight
1
/4" Swivel 2
5 88420 8-4.20 Hose,
1
/4" Swing to Valve, 20" 1
6 88425 8-4.25 Hose,
1
/4" Swing to Valve, 25" 1
1 2 3
456
21 3 12
6
5 4
