Terramite T6 - Model J-HP High Pressure Relief

Copyright © 1999 Terramite Corporation
Model J-HP High Pressure Relief
For Installation: Torque Relief
Valves Assembly to 45 ft. lbs.
[61 Nm]
QUANTITY
ITEM PER PLUG
NO. DESCRIPTION ASSEMBLY
1 BALL 1
2
SPRING, Relief (Model SP only) 1
SPRING, Relief (Models SPK and SSK only) 1
3 GASKET, Relief Body 1
4 O-RING, Adjusting Screw 1
5 O-RING, Valve Seat 1
6 BODY 1
7 SCREW, Adjusting 1
8 NUT, Jam, Adjusting Screw 1
9 NUT, Acorn Cap 1
10 GUIDE, Spring 1
11
WASHER, Spacer (SP) 1
WASHER, Spacer (SPK) 2
12 POPPET, Check 1
13 SEAT, Valve 1
}
Not Sold Separately
4.11
