Copyright © 1999 Terramite Corporation
Rear Axle Assembly
4.3
PART PREVIOUS DANA
ITEM NUMBER PART NUMBER DESCRIPTION PART NO. QTY.
1 55010 5-01 Housing-Axle *
2 64004 64004 Gear & Pinion Ass'y-Drive *
3 55030 5-03 Kit-Inner Pinion Bearing 706031X
4 55040 5-04 Shim-Drive Pinion Adjusting *
5 55050 5-05 Baffle-Pinion Bearing *
6 55060 5-06 Shim-Pinion Bearing Adjusting *
7 55070 5-07 Kit-Outer Pinion Bearing 706030X
8 55080 5-08 Slinger-Pinion Bearing Outer *
9 55090 5-09 Seal-Pinion 35723
10 55100 5-10 End Yoke Assembly 3-4-5761X
Continued On Next Page
