Copyright © 1999 Terramite Corporation
5.1
ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY.
1 85072 85072 Hose Guide 1
2 85010 85010 Strap - Hose Guide 1
3 22025 22025 Bolt,
1
/4" x
3
/4" LG 2
4 28504 28504 Nut, 1/4" - 28NF Lock, Plated 2
5 13000 13000 Pin, 1" x 5
1
/4", Front Curl Cylinder 1
6 20082 20082 Nut,
3
/8" - 16NC Flange 9
7 22174 22174 Fitting -
1
/4" Straight Male to
1
/4" Female Swivel 90° 2
8 81126 81126 Cylinder/A, Clam Bucket 2
9 17136 17136 Pin/w - Clam Cylinder (Rod End) 2
10 17138 17138 Pin/w - Clam Bucket Pivot 2
11 19358 19358 Clam/W - 4 in 1 1
12 19357 19357 Blade/w - 4 in 1 Clam 1
13 17137 17137 Pin/w - Clam Cylinder (Barrel End) 2
14 13200 13200 Pin, 1" x 4
3
/4"2
Clam Shell 4 in 1 Bucket (Factory Installed Option)
1 2 3 4 5 6 7 8 9 6 10 6
11126 13146
SEE NEXT PAGE
