T6 4WD Front Axle Assembly
3.4
A
B
C
D
(From Operators Position)
A 88465 8-4.65 Upper Port - Left Motor Cartridge Block - (SEE PAGE 3.6)
B 88465 8-4.65 Lower Port - Left Motor Cartridge Block - (SEE PAGE 3.6)
C 88465 8-4.65 Upper Port - Right Motor Cartridge Block - (SEE PAGE 3.6)
D 88465 8-4.65 Lower Port - Right Motor Cartridge Block - (SEE PAGE 3.6)
PART PREVIOUS
HOSE NUMBER PART NUMBER STARTING POINT ENDING POINT
E
A
F
B
