Terramite T6 - View from Left Side of Rear Axle - Drum Brake

Copyright © 1999 Terramite Corporation
ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY.
1 22056 SCR.NIPPLE.INS Chase Nipple
3
/4"2
2 22057 SCR.NIPPLE.NUT Chase Nipple Nut
3
/4"2
3 55000 55000 Axle, Rear w/Brakes Installed 1
4
55002 55002 Brake Shoe Assembly RH (Not Shown) 1
55003 55003 Brake Shoe Assembly LH (Not Shown) 1
5 55001 55001 Brake Drum 2
View from Left Side of Rear Axle - Drum Brake (After SN 6980506)
1 2 3 4 5
2.28
