Exploded View of Rear Transmission 4WD Brackets (After SN6981028 Dec. 98)
21
5 4 3
ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY.
1 22013 22013 Washer
3
/8"6
2 22044 22044 Bolt,
3
/8 -16NC x
3
/4 4
3 15087 15087 Bracket, Bottom Transmission 1
4 16182 16182 Bracket, Top Transmission 1
5 23001 23001 Nut, 3/8" - 16NC Lock, 4 WD 2
2.35
