Terramite T6 - View from Operator Position of Backhoe Valve

Copyright © 1999 Terramite Corporation
2.37
View from Operator Position of Backhoe Valve
ITEM PART NUMBER PREVIOUS PART NUMBER DESCRIPTION QTY.
1 25718 2507.10-8 Fitting,
7
/8" MP 90 x
1
/2" Swivel 1
2 21765 3107.6-4.R Fitting,
3
/8" MP x
1
/4" FP - Restrictor 2
3 21767 3107.6-6.R Fitting,
3
/8" MP x
3
/8" MP 45 Degrees - Restrictor 2
4 25286 0502.8-6 Fitting,
3
/4" MB x
3
/8" F - Bushing 12
5 20065 0502.12-8 Fitting, #12 O’Ring x
1
/2" FPT 2
6 21788 3107.8-8 Fitting,
1
/2" M x
1
/2" FM Swivel 45 3
7 21766 3107.6-6 Fitting,
3
/8" MP x
3
/8" MP 45 Degrees 8
23413 1-34.113 Restrictor w/Spring 3
1 2 3 4 5
66 7
NOT
SHOWN
