©2004 TESA Switzerland All Rights Reserved.
Page 1-8
User's Manual
MH3D
Description
The MH3D System consists of the
following main components:
1. Base
2. Granite Table
3. Y-Axis Rails
4. Bridge
5. Probe Locking Lever
6. Z-Rail
7. X-Z Carriage
8. Counterbalance Adjust Knob
9. Axis Lock Switches/Fine Adjust
Engagement
10. Probe
11. Control Box and VGA Monitor
12. Stand (optional)
13. ZMouse
14. Air Supply (rear)
15. Air Bearings (not visible)
16. Measuring System (not visible)
17. Machine Leveling Feet
18. Anti-tip Bolts
19. Granite Leveling Feet (not visible)
20. Fine Adjustment Knob
1
8
7
9
20
3
2
4 5
6-13
10
11
17
18
