User's Manual
MH3D
©2004 TESA Switzerland All Rights Reserved.
Page A-3
CCD Optical Probe - Installation
CAUTION
The optical probe is a delicate instrument and must be handled with
care. When not in use it should be stored in its original foam lined
box with the protective cap on the objective lens.
To install the optical video probe on the MH3D refer to the mounting configuration
and the connecting diagram and proceed as follows:
1. Lock the Z-rail.
2. Mount the optical probe in the probe holder at the end of the Z-rail and
tighten the clamping handle (2).
CAUTION
Never unlock the Z-rail until you are sure that the counterbalance
pressure is set correctly or the rail is firmly held.
3. If necessary, set the counterbalance pressure by holding the probe and
unlocking the Z-rail and then adjusting the counterbalance regulator.
4. To measure tall parts it may be necessary to invert the mounting bracket (4)
as shown. The support must be securely tightened.
5. Attach the cable support bracket (5) to the middle of the black cable tray
behind the X-rail.
6. Tie the the video cable, and the zoom control wire together using stay straps
7. Secure the cables to the brackets (4 and 5) with stay straps. The cables
must not interfere with the movements of the Z-rail or the ZX carriage.
8. Connect the components as shown in the connecting diagram.
The optional fiberoptic illuminator must be located as far away as possible
because of the heat generated by the illuminator.
Refer to the CCD Optics Instruction Manual for additional information.
