©2004 TESA Switzerland All Rights Reserved.
Page 1-12
User's Manual
MH3D
Specifications
PERFORMANCE METRIC ENGLISH
*Repeatability 0.003 mm 0.00012 in.
*Volumetric Accuracy 0.003+4.L/1000 0.0004 in.
*Linear Accuracy 0.003+3.L/1000 0.0002 in.
Resolution 0.00001 mm 0.0000025 in.
Display Range +/-9999.999 mm +/-999.99999 in.
Measuring Speed (Max.) 760 mm/sec 30 in/sec
DIMENSIONS
*Measuring Range 460 x 510 x 420 mm 18.4x20.4x16.6in.
Length 970 mm 38.8 in.
Width 930 mm 37.2 in.
Height 1620 mm 64.8 in.
Weight (Machine w/o granite) 98 kg 215 lbs
Weight (Complete system) 190 kg 416 lbs
Shipping Weight 250 kg 549 lbs
Maximum Part Weight 227 kg 500 lbs
Part Size Capability (X,Y,Z) 600 x 750 x 430mm 24 x 30 x 17.2 in.
OPERATIONAL REQUIREMENTS
Calibration Temperature 20°C±1°C 68°F±2°F
Operating Temp. Range 13° to 35°C 55.4° to 95°F
Storage Temperature -30° to 60°C -22° to 140°F
Air Input 4.8 - 8.3 BAR 70 - 120 psi
Air Consumption 21L/min @ 4 BAR .74 CFM @ 59 psi
Power Requirements 100 to 240 VAC 100 to 240 VAC
50/60 HZ 50/60 HZ
Power Consumption25 VA Max. 25 VA Max.
* Machine range when using 75 mm (3.0") long probe.
Repeatability, Volumetric and Linear Accuracy is measured with a 325mm
(12.8") Ball Bar in the center of machine sytem certified.
