TESA MH3D - Air System Diagram

©2004 TESA Switzerland All Rights Reserved.
Page 2-10
User's Manual
MH3D
Air System
Air bearings Right side
(Axe Y)
Air bearings left side
(Axe Y)
Left
back
Right
XYZ
back preload
Air bearings (Axe X)
rear preload
left preload
front preload
back
Right
P
A
R
F>
Z bearings
(049707)
(049745)
(049749)
(049723)
(049905)
(049905)
(049906)
back
back
Left
4,8 bar (70 psi)
(049746)
4,0 bar (58 psi)
4,8 bar (70 psi)
(049746)
4,0 bar (58 psi)
right
(Axe Y)
Patins jambe gauche
(Axe Y)
left
bottom
droite
X
Y
Z
bottom preload
Air bearings (Axe X)
back preload
left preload
front preload
left
bottom
right
bottom
P
A
R
F >
Bearings (Axe Z)
(049707)
(049745)
(049749)
(049945)
= 8 mm
= 4 mm
= 4 mm
bottom
