User's Manual
MH3D
©2004 TESA Switzerland All Rights Reserved.
Page 5-5
Glossary
Booting a System The process of activating or loading the software into the
computer. Powering the computer system so that the
operating software becomes functional.
Boss A circular raised projection on the surface of the work
piece.
Bridge The bridge is an inverted “U” shaped member that
moves in the Y direction and supports the X and Z
moving members.
Buffer A storage (holding) area in a computer for measurement
data.
CAD/CAM Computer-Aided Design, Computer-Aided Manufacture.
Calibrate To adjust a measuring instrument or inspect it for
accuracy.
Calibration Sphere An accessory used in qualifying the probe. A master
sphere.
Cartesian Feature output expressed as X, Y, and Z.
Cartesian A system used to describe points in space in terms of X,
Coordinates Y, and Z axes. The axes are perpendicular to each other.
The points are expressed in relation to some fixed origin
(zero point).
Cartesian Coordinate A measuring system that uses three independent,
Measuring System mutually perpendicular, axes to form a grid. The
coordinates of a point are measured as distances from
each of these axes.
Centroid The weighted center of all points that make up an
element.
Character Any letter, number, or punctuation mark that can be
typed from a keyboard or displayed on a screen.
Circle A geometric element defined by a minimum of three
points equidistant from a centerpoint. A measurement
routine used to compute the diameter and location of a
bored hole or a cylinder.
Circle-Circle A measurement routine which computes the shortest
Distance two-dimensional distance (working plane) between 2
circle center points.
Circularity The condition of a circle as it lies in a tolerance zone
formed by two concentric circles. Also called roundness.
