HYDRAULIC PULLER TENSIONER PT2450
Manual: MI-PT2450-050-00-GB Date: 28.07.2018 Author: AT Page: 41 of 89
5.5.2.3 Menù “SETTING MACHINE”
From the "Machine settings" menu it is possible to access the following sub-menus by pressing the relative
button:
• “Type of oil and circuit pressure control”;
• “General settings of the machine control panel”;
• “Machine work configuration”;
• Submenù “Type of oil and circuit pressure control”
1- Choosing the Oil Type (from AVG22 to AVG100);
2- Hydraulic oil temperature;
3- Pressure at the entrance of the hydraulic engine;
4- Pressure at the exit of the hydraulic engine;
5- Reel elevators circuit pressure;
6- Feeding circuit pressure about main hydraulic pump;
1
2
3
4
5
6
Type of oil and
circuit pressure
control
General settings
of the machine
control panel
Machine work
configuration
