HYDRAULIC PULLER TENSIONER PT2450
Manual: MI-PT2450-050-00-GB Date: 28.07.2018 Author: AT Page: 43 of 89
• Submenù “Machine work configuration”;
The puller-tensioner PT2450 have the possibility to work in this configuration:
a. Machine with independent bull-wheel;
b. Machine mechanical and hydraulic connected;
c. Machine electronic connected;
1- Button for machine configuration in mode “a” and “b”
This button allows to activate / deactivate the following working configurations of the machine with the
visualization, in the central part of the menu, of the active configuration
Machine with independent Bull-wheel.
Circuit 1 independent and completely separate from circuit 2.
Each single circuit be able to pull or tension until 50 KN.
Machine with mechanical and hydraulic connection
Circuit 1 is connected with circuit 2.
The machine can pull or tension until 100 KN.
2
3
4
Icon about the electronic
syncronize active
Machine working
configuration
