HYDRAULIC PULLER TENSIONER PT2450
Manual: MI-PT2450-050-00-GB Date: 28.07.2018 Author: AT Page: 71 of 89
b.2) On the panel of the machine N°2 – SLAVE, push the relative button, to connect the nearby in
machine N°3 – SLAVE
b.3) On the panel of the machine N°3 – SLAVE, push the relative button, to connect the nearby in
machine N°4 – SLAVE;
Is not necessary to make the above procedure for the MASTER machine.
At every connection, the icon of successful connection will appear on the control panel of the
single machine and the connection cable will turn green.
b.2)
b.3)
