HYDRAULIC PULLER TENSIONER PT2450
Manual: MI-PT2450-050-00-GB Date: 28.07.2018 Author: AT Page: 75 of 89
LEGENDA:
J = Joystick
1 = Circuit 1
2 = Circuit 2
S = machine SLAVE
M = machine MASTER
= command activated
= command de-activated
= with machine in TENSIONER configuration it’s possible to control the
“force value”
with the machine in PULLER configuration it’s possible to control the
“speed recover”
MACHINE IN INDIPENDENT CIRCUIT CONFIGURATION
STATUS SWITCH ON
SLAVE (S) MACHINE
STATUS SWITCH ON
MASTER (M) MACHINE
COMAND CIRCUIT MOVEMENT
+ +
J2M 2M
J1M 1M + 2S
J2S *
/
J1S 1S
+ +
J2M 2M+1M+2S
J1M *
/
J2S *
/
J1S 1S
+ +
J2M 2M+1M+2S+1S
J1M *
/
J2S *
/
J1S *
/
+ +
J2M 2M
J1M 1M+2S+1S
J2S *
/
J1S *
/
*
