HYDRAULIC PULLER TENSIONER PT2450
Manual: MI-PT2450-050-00-GB Date: 28.07.2018 Author: AT Page: 76 of 89
In the machine work configuration with "independent circuits" and "dependent circuits" the following
commands can be use:
- Active the synchronizer with the relative switch on the radio remote control on the MASTER machine;
- temporarily interrupt the radio control of the SLAVE or MASTER machine (see cap. 6.1.3)
MACHINE IN MECHANICAL CONNECTION BULL-WHEEL
STATUS SWITCH ON
SLAVE (S) MACHINE
STATUS SWITCH ON
MASTER (M) MACHINE
COMAND CIRCUIT MOVEMENT
+
+
J2M 2M+1M+2S+1S
J1M
*
/
J2S
*
/
J1S
*
/
