TESTING Vicat - Water Temperature Control Hysteresis; Heating Hysteresis; Cooling Set Point and Hysteresis

Single Station Vicat Test Apparatus
1.0360
16
3.4.2 Setting the Hysteresis for the heating
Figure 10: setting hysteresis heating
One-time short press of the button increases the hysteresis by 0.1 °C.
Pressing and hold down this button increases the hysteresis continuously by 0.1 °C.
If you press and hold the button for more than 3 seconds, the step size increases to 1 °C.
This process continues until either you release the button or you reach the maximum permissible value.
One-time short press of the button decreases the hysteresis by 0.1 °C.
Pressing and hold down this button decreases the hysteresis continuously by 0.1 °C.
If you press and hold the button for more than 3 seconds, the step size increases to 1 °C.
This process continues until you either release the button or you reach the minimum permissible value.
To get the set value also after switching off the device press the button.
3.4.3 Setting the set point for the cooling
Proceed as in the section (3.4.1).
3.4.4 Setting the hysteresis for the cooling
Proceed as in the section (3.4.2).
Settings> water heating/cooling>
hysteresis heating
0.5 °C
