TESTING Vicat - Humidity Sensor Calibration; Adjusting Slope and Zero Voltage

Single Station Vicat Test Apparatus
1.0360
23
3.7.1 Adjusting the slope of the humidity sensor
Figure 16: Adjusting the slope of the humidity sensor
Use the key pad to insert the desired value
Decimal delimiter
Delete digit
To get the set value also after switching off the device press the button.
3.7.2 Adjusting the zero voltage of the humidity sensor
Figure 17: Adjusting the zero voltage of the humidity sensor
Proceed as in the section (3.7.1).
Settings> Humidity sensor>Slope
mV/%rH
30.08885
Settings> Humidity sensor >Zero voltage
Volt
0.835126
