TESTING Vicat - Needle Replacement; Procedure for Replacing Needle

Single Station Vicat Test Apparatus
1.0360
41
5.3 Replacing the needle
4. Reinsert the drop rod and lock the flap.
Figure 36: Replacing the needle
1. Loosen the knurled screws to open the flap.
2. Remove the drop rode.
3. Loosen the screw and re-
place the needle.
