TESTING Vicat - Heat Sink Temperature Settings; Upper and Lower Limits; Run-on Temperature and Sensor T2 Correction

Single Station Vicat Test Apparatus
1.0360
20
3.6.1 Setting the upper temperature of heat sinks
Figure 14: Upper temperature of the heat sinks
One-time short press of the button increases the value by 0.1 °C.
Pressing and hold down this button increases the value continuously by 0.1 °C.
If you press and hold the button for more than 3 seconds, the step size increases to 1 °C.
This process continues until you either release the button or you reach the maximum permissible value.
One-time short press of the button decreases the value by 0.1 °C.
Pressing and hold down this button decreases the value continuously by 0.1 °C.
If you press and hold the button for more than 3 seconds, the step size increases to 1 ° C.
This process continues until you either release the button or you reach the minimum permissible value.
To get the set value also after switching off the device press the button.
3.6.2 Setting the lower temperature of heat sinks
Proceed as in the section 3.6.1).
3.6.3 Setting the run-on temperature of the heat sinks
Proceed as in the section 3.6.1).
3.6.4 Setting the correction factor for sensor T2
Proceed as in the section 3.4.5).
Settings> Airflow flow control>
Upper temperature of the heat sinks
60.0 °C
