Single Station Vicat Test Apparatus
1.0360
17
3.4.5 Setting the correction factor for sensor T1
We use a TSIC306 temperature sensor for water temperature control.
The TSIC306 has a measuring range from -50 °C to 150 °C with a resolution of 0.1K.
The measuring accuracy is 0.3 K in the range 10 ... 90 °C and 0.5 K outside this range.
The correction factor adjusts the absolute temperature of the sensor to a more accurate referencing instru-
ment.
TRef = TSens correction factor
Pressing the
button on the Settings>water heating/cooling page let you edit the
correction factor (Figure 11).
Figure 11: setting correction factor for sensor T1
One-time short press of the button increases the correction factor by 0.1 °C.
Pressing and hold down this button increases the correction factor continuously by 0.1 °C.
If you press and hold the button for more than 3 seconds, the step size increases to 1 °C.
This process continues until you either release the button or you reach the maximum permissible value.
One-time short press of the button decreases the correction factor by 0.1 °C.
Pressing and hold down this button decreases the correction factor continuously by 0.1 °C.
If you press and hold the button for more than 3 seconds, the step size increases to 1 ° C.
This process continues until you either release the button or you reach the minimum permissible value.
To get the set value also after switching off the device press the button.
Correction factor
