6 Using the product
51
• Repeated testing PS >0.5 bar
Pipelines with PS >0.5 bar must be subjected to a pressure test
every 10 years. Pipelines with DN > 25 must be subjected to a
main test under operating conditions every 2 years.
• Repeated testing PS <=0.5 bar
Pipelines with PS <=0.5 bar must be subjected to a main test
every 10 years.
6.2.5.1. Pressure test
Calling up the function:
> [] → Measurements → [OK] → Liquid gas (TRF) →
Pressure test → [OK].
Setting parameters
Parameter Explanation
Stability time Set stability time
TRF 2012 stipulates a stability
time of 10 min.
Measurement period Set measurement period
TRF 2012 stipulates a
measurement period of 10 min.
Test pressure (target) Set test pressure
TRF 2012 stipulates a test
pressure of 1000 mbar.
1. Edit values: [Edit].
2. Enter values. [▲], [▼] and sometimes [◄], [►] → [OK].
Carrying out a pressure test
1. Build up test pressure (target) manually with the test pump or a
compressor at the connection provided.
2. Start measurement: [].
- Zeroing starts (5 s)
Option
> End stability time early: [Next]
> End measurement period early: [Next]
- Measurement is cancelled.
- Pressure test is ended.
