6 Using the product
68
Carry out the steps according to the notes on the display and
confirm with [OK].
If the set test pressure (target) is greater than 300 mbar, the
test pressure must be built up manually.
Option
> End stability time early: [Next]
> End measurement period early: []
- Measurement is cancelled.
2. Save measurement result: [OK].
Options
> [Options] → Show Graphic: a section of past measuring
values is displayed in a line graph (zoom function available [▲],
[▼]).
> [Options] → Configure Graphic: the measurement
parameters to be represented (max. 4) can be displayed ( ) or
hidden ( ).
> [Options] → Number of lines: change the number of
measuring values per display page.
> [Options] → Manometer: the measuring values are displayed
in the same way.
> [Options] → Measurement view: (this function is not available
during a measurement): The reading display menu is opened.
Up to 8 measurement parameters can be selected.
> [Options] → Overall graphic curve: the measuring values
across the overall measuring time are displayed in a line graph.
6.2.9. Controller test
There are 4 different test types to choose from:
Test type Explanation
Static pressure
The static pressure measurement
enables defects in the pressure reducer
(controller) and the shut-off valve (ball
valve) upstream of the consumer to be
detected.
Flow pressure
The flow pressure measurement enable
defects in the pressure reducer
(controller) to be detected.
