6 Using the product
65
6.2.8.2. Programs 2-5
Four measurement programs for different measurement types can
be configured and enabled. The measurement programs are used
to save and represent measuring sequences. At the end of the
measuring process, the measuring values of a measurement
program are automatically saved in a record.
Only one measurement program can be activated in the instrument.
Call up the function:
> [] → Measurements → [OK] → Programs → [OK].
Selecting and setting a program:
> Select and set program and then confirm with [Finished].
Setting options:
Parameter Function
Program
1. Select the program: [▲], [▼] → [Edit].
2. Edit program name: → [Edit] → [▲], [▼]
and sometimes [◄], [►] → [OK].
3. Save changes: [Finished].
Configure
measurement
view
1. Select the program: [▲], [▼] → [Edit].
2. Select Measurement view: [▼] → [Edit].
3. Select parameter: [▲], [▼] → []
(enabled), [] (disabled), tee table below
4. Save changes: [Finished].
Meastime
1. Select the program: [▲], [▼] → [Edit].
2. Select Gas time: [▼] → [Edit].
3. Enter values. [▲], [▼] and sometimes [◄],
[►] → [OK].
4. Save changes: [OK].
Measuring rate
The measuring rate is the storage cycle for
mean values It is programmed in units of
seconds, minutes, whereby the smallest
possible measuring rate depends on the
number and type of connected probes.
1. Select the program: [▲], [▼] → [Edit].
2. Select Measuring rate: [▼], [►] → [Edit].
3. Enter values. [▲], [▼] and sometimes [◄],
[►] → [OK].
4. Save changes: [OK].
