Table 3-24. Selection of PRG0 Signals on Application Connector (continued)
Connector
Pin SoC Ball Net Name Pin Multiplexed Signal Functions
B14 Y3 PRG0_PRU0GPO11 PRG0_PRU0_GPI11, PRG0_RGMII1_TD0,
PRG0_PWM3_TZ_OUT, GPIO1_11, UART4_RXD
B15 Y4 PRG0_PRU1GPO12 PRG0_PRU1_GPI12, PRG0_RGMII2_TD1,
PRG0_PWM1_A0, GPIO1_32, EQEP2_B,
GPMC0_A7, UART4_TXD
B16 - DGND -
B17 - PRG0_HSE_ETH2_CLK -
B18 - DGND -
B19 - DGND -
B20 Y21 GPMC0_AD14 FSI_TX0_D0, UART6_RXD,EHRPWM3_B,
TRC_DATA12, GPIO0_29, PRG0_PWM3_B0,
BOOTMODE14
B21 R16 GPMC0_AD10 FSI_RX0_D1, UART4_CTSn, EHRPWM_TZn_IN2,
EHRPWM8_B, TRC_DATA8, GPIO0_25,
PRG1_PWM2_B2, BOOTMODE10
B22 - HSE_GPIO0_31 -
B23 - DGND -
B24 - HSE_GPIO0_35 -
B25 - DGND -
B26 - DGND -
B27 - DGND -
B28 - DGND -
B29 AA5 HSE_PRG0_PRU0_GPO10 PRG0_PRU0_GPI10, PRG0_UART0_RTSn,
PRG0_PWM2_B1, RGMII1_RXC, RMII_REF_CLK,
PRG0_IEP0_EDIO_DATA_IN_OUT29,GPIO1_10,
UART3_RXD
B30 - DGND -
D1 B14 SOC_SPI1_CS0 EHRPWM6_A, GPIO1_47
D2 D14 SOC_SPI1_CS1 CPTS0_TS_SYNC, I2C2_SDA,
PRG1_IEP0_EDIO_OUTVALID, UART6_TXD,
ADC_EXT_TRIGGER1, GPIO1_48, TIMER_IO11
D3 B12 MCU_RESETZ -
D4 - DGND -
D5 T6 PRG0_PRU1GPO13 PRG0_PRU1_GPI13, PRG0_RGMII2_TD2,
PRG0_PWM1_B0, GPIO1_33, EQEP0_I, GPMC0_A8,
UART5_RXD
D6 P4 PRG0_PRU1GPO5 PRG0_PRU1_GPI5, GPIO1_25, EQEP1_S,
UART6_RTSn
D7 - DGND -
D8 T3 PRG0_PRU0GPO6 PRG0_PRU0_GPI6, PRG0_RGMII1_RXC,
PRG0_PWM3_A1, GPIO1_6, UART4_CTSn
D9 V3 PRG0_PRU1GPO2 PRG0_PRU1_GPI2, PRG0_RGMII2_RD2,
PRG0_PWM2_A2, GPIO1_22, EQEP0_S,
UART5_RTSn
D10 - DGND -
D11 W4 PRG0_PRU1GPO11 PRG0_PRU1_GPI11, PRG0_RGMII2_TD0,
GPIO1_31, EQEP2_I, UART4_RXD
D12 T5 PRG0_PRU0GPO15 PRG0_PRU0_GPI15, PRG0_RGMII1_TX_CTL,
PRG0_PWM0_B1, SPI3_CS1, GPIO1_15,
GPMC0_A16
D13 - DGND -
System Description www.ti.com
50 AM64x/AM243x GP EVM User's Guide SPRUIX0C – FEBRUARY 2021 – REVISED JUNE 2021
