4.2.2 Aardvark Adapter
Although the Total Phase Aardvark adapter will physically mate to the EVM J3 connector, the pinout is
incompatible. A special interface cable must be constructed to use the Aardvark. Refer to the schematics
and Table 7 below for information.
CAUTION
Do not connect the Aardvark to the EVM without a properly constructed cable.
Damage may result to the EVM and/or Aardvark.
Table 7. Adapter Cable Pinout
IC Pin Name or Description USB-TO-GPIO (Mates to J3) Aardvark
Pin Signal Pin Signal
VSS – signal reference 6 GND 2 GND
SCLK 9 SCL 1 SCL
SDATA 10 SDA 3 SDA
ZEDE – communication enable 4 GPIO4 5 MISO/GPIO
Programming voltage control signal for
3 GPIO5 7 SCLK/GPIO
EEPROM
4.3 Installing the bq77908-10-GUI-SW Evaluation Software
Find the latest software version in the bq77908-10-GUI-SW Evaluation Software tool folder
http://www.ti.com/tool/bq77908-10-gui-sw or search from power.ti.com. Check periodically for software
updates. Use the following steps to install the bq77910A Evaluation Software:
1. Copy the archive file to a directory of your choice, extract and run the bq77910A setup.msi installer.
2. Follow the instructions and make selections as required on the setup windows selecting next as
required.
3. On the last window, select "close" to complete the bq77910A software installation.
5 Software Operation
This section describes connection of the communication interface to the EVM and operation of the
software.
Although the software will run without connection to a powered device it is recommended to have the
device on when starting the software. Figure 3 shows connections for operation with the GUI software.
