bq77910A Circuit Module Physical Construction
www.ti.com
8.1.2 Bill of Materials
The bill of materials for the circuit module is shown in Table 10. Substitute parts may be used in the
manufacturing of the assembly.
Table 10. bq77910A Circuit Module Bill of Materials
Count Reference Design Value Description Size Part Number Manufacturer
17 C1, C4, C18, C19, C20, 0.1 μF Capacitor, Ceramic, 50V, X7R, 10% 0603 Std Std
C23, C24, C25, C27,
C28, C29, C31, C32,
C34, C35, C36, C37
1 C12 0.1 µF Capacitor, Ceramic, 50V, X7R, 10% 1210 Std Std
1 C15 10 nF Capacitor, Ceramic, 50V, X7R, 10% 0603 Std Std
1 C17 4.7 µF Capacitor, Ceramic, 50V, X7R, 10% 1210 Std Std
1 C2 10 µF Capacitor, Ceramic, 50V, Y5V, 20% 1210 Std Std
2 C21, C26 1 µF Capacitor, Ceramic, 25V, X5R, 10% 1206 Std Std
0 C22 Capacitor, 0603, Not installed 0603
11 C3, C5, C6, C7, C8, C9, 1 µF Capacitor, Ceramic, 10V, X7R, 10% 0603 Std Std
C10, C11, C13, C14, C16
0 C30 Capacitor, 1206, Not installed 1206
0 C33 Capacitor, Ceramic, 50V, X7R, 10% 0603
3 D1, D8, D12 ** 40V TVS Diode, TVS, Unidirectional, 600-W SMB 1SMB40AT3G ON Semiconductor
2 D10, D11 MURD620CT Diode, Fast rectifier, 200V, 5A D-PAK MURD620CTG or ON Semiconductor or
UF5A400D1-13 or Diodes or Rohm
RF505B6STL
0 D13, D14, D15, D16, D17 Diode, TVS, Pattern only, 600-W SMB
1 D18 ** 17V TVS Diode, TVS, Unidirectional, 600-W SMB 1SMB17AT3G ON Semiconductor
4 D2, D4, D5, D6 1N4148W Diode, Signal, 300-mA, 75-V, 350-mW SOD-123 1N4148W-7-F Diodes
1 D3 AZ23C5V6 Diode, Dual, Zener, 5.6V, 300mW SOT23 AZ23C5V6 Vishay-Telefunken
0 D7 Diode, Signal, 300-mA, 75-V, 350-mW SOD-123
1 D9 ** 40V TVS Diode, Unidirectional TVS, 1500W SMC SMCJ40A Littelfuse
1 HS1 581102B02500G Heatsink, TO-220/218 vertical 0.640 x 0.640 inch 581102B02500G Aavid Thermalloy
0 HS2 Heatsink, Pattern only,TO-220/218 vertical 0.640 x 0.640 inch
2 J1, J2 PEC02SAAN Header, Male 2-pin, 100mil spacing 0.100 inch x 2 PEC02SAAN Sullins
0 J8 Header, Male 2-pin, 100mil spacing
4 J10, J12, J15, J16 1714955 Header, 32A, 500V, 2-pin, 250 mil spacing 0.492 x 0.500 inch 1714955 Phoenix Contact
4 J11, J13, J14, J17 3267 Connector, Banana Jack, Uninsulated 0.500 dia. inch 3267 Pomona
0 J18 Header, 11-pin, 100mil spacing, 0.100 inch x 11
1 J3 5103308-1 Header, 2x5-pin, 100mil spacing 0.330 x 0.800 inch 5103308-1 Tyco
1 J4 ** 1803455 Header, 8A 300V, 5-pin Vert. Entry 0.280 x 0.700 inch 1803455 Phoenix Contact
1 J5 ** 1803468 Header, 8A 300V, 6-pin Vert. Entry 0.2800 x 0.750 inch 1803468 Phoenix Contact
1 J6 PEC03SAAN Header, Male 3-pin, 100mil spacing, 0.100 inch x 3 PEC03SAAN Sullins
1 J7 ED555/2DS Terminal Block, 2-pin, 6-A, 3.5mm 0.27 x 0.25 inch ED555/2DS OST
1 J9 ED555/3DS Terminal Block, 3-pin, 6-A, 3.5mm 0.41 x 0.25 inch ED555/3DS OST
1 Q1 BSS84 MOSFET, Pch, -50V, -0.13A, 10 Ω SOT23 BSS84 Fairchild
1 Q2 BSS138 MOSFET, Nch, 50V, 0.22A, 3.5 Ω SOT23 BSS138 Fairchild
1 Q3 IRFB3207ZPBF MOSFET, Nchan, 75V, 170A, 4.1 mΩ TO-220AB IRFB3207ZPBF IR
0 Q4, Q5, Q6 MOSFET, Nchan, Pattern only TO-220AB
1 Q7 IRFB3607PBF MOSFET, Nchan, 75V, 80A, 9 mΩ TO-220AB IRFB3607PBF IR
3 R1, R16, R17 1M Resistor, Chip, 1/16W, 5% 0603 Std Std
2 R10, R37 100k Resistor, Chip, 1/16W, 5% 0603 Std Std
3 R2, R6, R46 47k Resistor, Chip, 1/16W, 5% 0603 Std Std
9 R23, R33, R35, R36, 1k Resistor, Chip, 1/16W, 5% 0603 Std Std
R38, R41, R43, R44, R47
4 R24, R27, R34, R39 10k Resistor, Chip, 1/16W, 5% 0603 Std Std
1 R28 47 Resistor, Chip, 1/16W, 5% 0603 Std Std
3 R3, R42, R59 0 Resistor, Chip, 1/16W, 5% 0603 Std Std
0 R30, R51, R53, R54, Resistor, Chip, 1/16W, 5% 0603
R55, R56, R57, R58,
R60, R61, R62, R63, R65
1 R4 200 Resistor, Metal Film, 1/4 watt, ± 5% 1206 Std Std
2 R48, R49 5.1M Resistor, Chip, 1/16W, 5% 0603 Std Std
28
bq77910AEVM SLUU855–February 2012
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated
