DS90UB954-Q1EVM Quick Start
15 DS90UB954Q1-EVM Bill of Materials
Table 13. DS90UB954-Q1EVM BOM
ITEM QTY DESIGNATOR VALUE PART NUMBER MANUFACT
URER
DESCRIPTION
1 1 !PCB1 HSDC007 Any Printed Circuit Board
2 2 C1, C8 220pF 06035A221FAT2A AVX CAP, CERM, 220 pF, 50 V, +/- 1%,
C0G/NP0, 0603
3 1 C2 0.01uF C1608X7R1H103K080AA TDK CAP, CERM, 0.01 µF, 50 V, +/-
10%, X7R, 0603
4 5 C3, C13, C14,
C75, C111
0.1uF 0603YC104JAT2A AVX CAP, CERM, 0.1 µF, 16 V, +/- 5%,
X7R, 0603
5 2 C4, C12 0.1uF GRM155R71C104KA88D MuRata CAP, CERM, 0.1 µF, 16 V, +/-
10%, X7R, 0402
6 1 C5 1uF C0805C105K3RACTU Kemet CAP, CERM, 1 µF, 25 V, +/- 10%,
X7R, 0805
7 1 C6 2.2uF 0805YD225KAT2A AVX CAP, CERM, 2.2 µF, 16 V, +/-
10%, X5R, 0805
8 1 C7 22uF EEE-1AA220WR Panasonic -
ECG
CAP ALUM 22UF 10V 20% SMD
9 2 C9, C10 30pF GRM1885C2A300JA01D MuRata CAP, CERM, 30 pF, 100 V, +/- 5%,
C0G/NP0, 0603
10 1 C11 2200pF C0603X222K5RACTU Kemet CAP, CERM, 2200 pF, 50 V, +/-
10%, X7R, 0603
11 4 C15, C19, C105,
C109
4.7uF GRM21BR71C475KA73L MuRata CAP, CERM, 4.7uF, 16V, +/-10%,
X7R, 0805
12 5 C16, C20, C110,
C114, C123
10uF GRM21BR71A106KE51L MuRata CAP, CERM, 10uF, 10V, +/-10%,
X7R, 0805
13 12 C17, C18, C21,
C22, C51, C113,
C116, C117,
C121, C122,
C125, C128
0.1uF GRM155R71C104KA88D MuRata CAP, CERM, 0.1uF, 16V, +/-10%,
X7R, 0402
14 1 C23 10pF GRM1555C1H100JA01D MuRata CAP, CERM, 10pF, 50V, +/-5%,
C0G/NP0, 0402
15 1 C24 3300pF GRM155R71H332KA01D MuRata CAP, CERM, 3300pF, 50V, +/-
10%, X7R, 0402
16 2 C25, C124 1uF GCM188R71C105KA64D MuRata CAP, CERM, 1 µF, 16 V, +/- 10%,
X7R, AEC-Q200 Grade 1, 0603
17 9 C26, C28, C30,
C31, C101, C102,
C104, C119,
C120
1uF GRM185R61C105KE44D MuRata CAP, CERM, 1 µF, 16 V, +/- 10%,
X5R, 0603
18 1 C27 10uF GRM188R61E106MA73D MuRata CAP, CERM, 10 µF, 25 V, +/-
20%, X5R, 0603
19 14 C29, C34, C40,
C41, C48, C49,
C53, C54, C62,
C67, C81, C86,
C87, C93
22uF GRT31CR61E226KE01L MuRata CAP, CERM, 22 µF, 25 V,+/- 10%,
X5R, AEC-Q200 Grade 3, 1206
20 2 C32, C35 22uF GRT31CR61E226KE01L MuRata CAP, CERM, 22 µF, 25 V, +/-
10%, X5R, AEC-Q200 Grade 3,
1206
21 8 C33, C42, C47,
C63, C66, C71,
C78, C79
0.1uF CGA2B3X7R1H104K050BB TDK CAP, CERM, 0.1 µF, 50 V, +/-
10%, X7R, AEC-Q200 Grade 1,
0402
22 4 C36, C43, C61,
C72
4.7uF C0805C475K3PACTU Kemet CAP, CERM, 4.7 µF, 25 V, +/-
10%, X5R, 0805
