www.ti.com DS90UB954Q1-EVM Bill of Materials
45
SNLU223–August 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
DS90UB954-Q1EVM Quick Start
Table 13. DS90UB954-Q1EVM BOM (continued)
ITEM QTY DESIGNATOR VALUE PART NUMBER MANUFACT
URER
DESCRIPTION
23 9 C37, C44, C45,
C60, C64, C65,
C68, C77, C80
0.01uF GCM155R71H103KA55D MuRata CAP, CERM, 0.01uF, 50V, +/-10%,
C0G/NP0, 0402
24 3 C38, C39, C83 0.033uF CGA2B3X7R1H333K050BB TDK CAP, CERM, 0.033 µF, 50 V, +/-
10%, X7R, AEC-Q200 Grade 1,
0402
25 8 C46, C59, C73,
C82, C100, C103,
C112, C118
1uF C1005JB1V105K050BC TDK CAP, CERM, 1 µF, 35 V, +/- 10%,
JB, 0402
26 2 C50, C106 0.1uF C1005X5R1H104K050BB TDK CAP, CERM, 0.1 µF, 50 V, +/-
10%, X5R, 0402
27 4 C52, C56, C130,
C131
4700pF 08051C472KAT2A AVX CAP, CERM, 4700 pF, 100 V, +/-
10%, X7R, 0805
28 2 C55, C58 12pF GRM1555C1E120JA01D MuRata CAP, CERM, 12pF, 25V, +/-5%,
C0G/NP0, 0402
29 3 C57, C88, C92 10uF CL21A106KAFN3NE Samsung CAP, CERM, 10 µF, 25 V, +/-
10%, X5R, 0805
30 4 C69, C94, C99,
C127
22uF 293D226X0025D2TE3 Vishay-
Sprague
CAP, TA, 22uF, 25V, +/-20%, 0.7
ohm, SMD
31 5 C70, C85, C90,
C96, C98
0.1uF C1005X7R1H104K050BB TDK CAP, CERM, 0.1 µF, 50 V, +/-
10%, X7R, 0402
32 1 C74 0.01uF 06031C103KAT2A AVX CAP, CERM, 0.01 µF, 100 V, +/-
10%, X7R, 0603
33 1 C76 0.047uF C1005X7R1H473K050BB TDK CAP, CERM, 0.047 µF, 50 V, +/-
10%, X7R, 0402
34 1 C84 0.015uF CGA2B3X7R1H153K050BB TDK CAP, CERM, 0.015 µF, 50 V, +/-
10%, X7R, AEC-Q200 Grade 1,
0402
35 4 C89, C91, C95,
C97
10uF C1608X5R1E106M080AC TDK CAP, CERM, 10 µF, 25 V, +/-
20%, X5R, 0603
36 1 C107 47uF GRM32ER61C476ME15L MuRata CAP, CERM, 47uF, 16V, +/-20%,
X5R, 1210
37 1 C108 100uF T495D107M016ATE100 Kemet CAP, TA, 100uF, 16V, +/-20%, 0.1
ohm, SMD
38 1 C115 0.01uF 06031C103JAT2A AVX CAP, CERM, 0.01uF, 100V, +/-5%,
X7R, 0603
39 1 C126 0.47uF GRM188R71A474KA61D MuRata CAP, CERM, 0.47 µF, 10 V, +/-
10%, X7R, 0603
40 1 C129 2.2uF 293D225X9025A2TE3 Vishay-
Sprague
CAP, TA, 2.2uF, 25V, +/-10%, 6.3
ohm, SMD
41 9 D1, D8, D10, D11,
D12, D13, D14,
D15, D16
Green 150060VS75000 Wurth
Elektronik
eiSos
LED, Green, SMD
42 1 D2 7.5V 1SMB5922BT3G ON
Semiconduct
or
Diode, Zener, 7.5 V, 550 mW,
SMB
43 3 D3, D4, D5 Super
Red
150060SS75000 Wurth
Elektronik
eiSos
LED, Super Red, SMD
44 3 D6, D7, D9 Orange LTST-C190KFKT Lite-On LED, Orange, SMD
45 1 D17 40V 1N5819HW-7-F Diodes Inc. Diode, Schottky, 40V, 1A, SOD-
123
46 1 F1 0440002.WR Littelfuse Fuse, 2 A, 32 V, SMD
47 1 FB1 60 ohm BK1608HS600-T Taiyo Yuden Ferrite Bead, 60 ohm @ 100 MHz,
0.8 A, 0603
