DS90UB954Q1-EVM Bill of Materials www.ti.com
46
SNLU223–August 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
DS90UB954-Q1EVM Quick Start
Table 13. DS90UB954-Q1EVM BOM (continued)
ITEM QTY DESIGNATOR VALUE PART NUMBER MANUFACT
URER
DESCRIPTION
48 6 FID1, FID2, FID3,
FID4, FID5, FID6
N/A N/A Fiducial mark. There is nothing to
buy or mount.
49 1 H1 BMI-S-201-F Laird EMI SHIELD, 13.66 x 12.70 mm,
SMT
50 4 H1, H2, H5, H6 NY PMS 440 0025 PH BF Fastener
Supply
Machine Screw, Round, 4-40 x 1/4,
Nylon, Philips panhead
51 1 J1 PJ-102A CUI Inc. Connector, DC Jack 2.1X5.5 mm,
TH
52 1 J2 1734035-2 TE
Connectivity
Connector, Receptacle, Mini-USB
Type B, R/A, Top Mount SMT
53 7 J3, J13, J14, J17,
J18, J23, J28
5-146261-1 TE
Connectivity
Header, 100mil, 2x1, Gold plated,
TH
54 5 J6, J9, J10, J12,
J16
TSW-103-07-G-S Samtec, Inc. Header, TH, 100mil, 3x1, Gold
plated, 230 mil above insulator
55 1 J7 TSW-102-07-G-D Samtec Header, 100mil, 2x2, Gold, TH
56 4 J8, J11, J15, J27 TSW-104-07-G-D Samtec Header, 100mil, 4x2, Gold, TH
57 1 J21 MMCX-J-P-H-ST-TH1 Samtec Connector, MMCX 50 ohm, TH
58 1 J22 TSW-110-07-G-D Samtec Header, 100mil, 10x2, Gold, TH
59 1 J24 QSH-020-01-H-D-DP-A Samtec Receptacle, Differential, 0.5mm, 10
pair x2, Gold, SMT
60 1 J25 0022112042 Molex Header, 100mil, 4x1, White, TH
61 1 J26 QTH-020-04-L-D-DP-A Samtec Header(shrouded), 0.5mm, 10 pair
x 2, Gold, SMT
62 3 J29, J30, J31 59S20X-40ML5-Z Rosenberger Connector, RF, 50 Ohm, R/A, TH
63 8 L1, L2, L3, L4, L5,
L6, L7, L8
120
ohm
BLM18SG121TN1D MuRata Ferrite Bead, 120 ohm @ 100
MHz, 3 A, 0603
64 2 L10, L18 100uH CLF6045NIT-101M-D TDK Inductor, Wirewound, Ferrite, 100
µH, 0.61 A, 0.32 ohm, AEC-Q200
Grade 0, SMD
65 1 L11 10uH LQH3NPN100NG0 MuRata Inductor, Wirewound, Ferrite, 10
µH, 0.5 A, 0.57 ohm, SMD
66 1 L12 DLW21SN900HQ2L MuRata Coupled inductor, 0.28 A, 0.41
ohm, +/- 25%, SMD
67 2 L13, L20 1000
ohm
BLM18AG102SN1D MuRata Ferrite Bead, 1000 ohm @ 100
MHz, 0.4 A, 0603
68 1 L14 330
ohm
MPZ1005S331ETD25 TDK Ferrite Bead, 330 ohm @ 100
MHz, 0.7 A, 0402
69 2 L15, L16 1500
ohm
BLM18HE152SN1D MuRata Ferrite Bead, 1500 ohm @ 100
MHz, 0.5 A, 0603
70 1 L17 47 ohm MPZ1005F470ETD25 TDK Ferrite Bead, 47 ohm @ 100 MHz,
0.45 A, 0402
71 1 L19 10uH LQH3NPN100MJRL MuRata Inductor, Wirewound, Ferrite, 10
µH, 0.81 A, 0.24 ohm, SMD
72 1 L21 4.7uH 7440650047 Wurth
Elektronik
Inductor, Shielded Drum Core,
Ferrite, 4.7 µH, 4.2 A, 0.02 ohm,
SMD
73 2 Q1, Q2 50V BSS138 Fairchild
Semiconduct
or
MOSFET, N-CH, 50 V, 0.22 A,
SOT-23
74 1 R1 200 CRCW0603200RFKEA Vishay-Dale RES, 200, 1%, 0.1 W, 0603
75 1 R2 1.5k CRCW04021K50JNED Vishay-Dale RES, 1.5k ohm, 5%, 0.063W, 0402
76 2 R3, R10 33k CRCW040233K0JNED Vishay-Dale RES, 33k ohm, 5%, 0.063W, 0402
77 1 R4 1.2Meg CRCW06031M20JNEA Vishay-Dale RES, 1.2 M, 5%, 0.1 W, 0603
